More info
S6-EA3P(5-10)K series is a new generation of three-phase AC Coupled products, designed to provide photovoltaic energy storage upgrading solutions for the built grid-tied system, The system transformation is convenient, with low investment costs and no impact on existing lines. Battery voltage range is 120~600V, the maximum charging and discharging current reaches 50A, capable of adapting to mainstream high-voltage battery systems in the market, fully leveraging the performance of the battery system, flexibly matching multiple battery solutions, and reducing the investment cost of your battery system. Supported 6-stage timed charge and discharge function, significantly enhance the energy efficiency of the energy storage system and optimize the cost-effectiveness of household energy usage. Integrated battery treatment and protection functions to extend battery life.
Features:
Max. charge/discharge current up to 50A
Supports peak shaving control
Compatible with multiple brands of lithium battery models
Dual RS485 port, supports remote upgrade and VPP remote control
Real-time battery monitoring, remote upgrade, and battery healing function to prolong battery life
Supports six different battery charging and discharging TOU (Time of Use) settings to lower your electricity bill
AC rated power: 10 kW
Charging/discharging power: 10 kW
Charging current: 50 A
Discharging current: 50 A
Number of phases: 3
Max. efficiency: 97.50%
Dimensions: 600 × 500 × 230 mm
Weight: 26.9 kg
