Power Sonic 29.2V 10A 292W Charger for LiFePO4 battery

PSC-2410000-LIFE-EU

New

5 Products in stock in our warehouse.

€ 145,78

 tax 0% incl.

€ 181,78

-€ 36,00

Download

Data sheet

Type LiFePO4 battery charger
Style Home charger
Target platform Battery accessories, Battery chargers
Compositions Plastic
Amperage 10A
Voltage 220-240V
Characteristics Short circuit protection
Color characteristics Black
Warranty 2 years
Made in European Union
Manufacturing number PSC-2410000-LiFe-EU

More info

The PSC-2410000-LiFe-EU is part of our LiFe series of 3-step LiFePO4 battery chargers The LiFe Series of lithium chargers feature an intelligent 3-step charging logic which can help charge even the deepest of discharged batteries To maximize battery performance and battery life the optimized charging technology makes the best possible use of the capabilities of the batteries to be charged The 8-cell 10000mA charger has been medically certified to both EN60601-1 3 1 and EN60601-1-2 4 making it the ideal choice for any medical application or anyone looking for a top quality charger The PSC-2410000-LiFe battery charger is manufacture using the highest quality components and manufacturing process

FEATURES:
• 3-step charge control with current detection
• Input voltage 198 - 264 VAC
• Wake up and low current start-up of deeply discharged batteries
• Error indication for reverse polarity, defect battery & safety timer run-out

PERFORMANCE SPECIFICATIONS:
Input voltage: 198 - 264 VAC
Line frequency: 47 – 50Hz
Switch frequency, approx: 65 kHz
Leakage current from battery with mains switched off: 160μ[email protected]
Operating temperature: -25 °C - +40 °C
Storage temperature: -25 °C - +65 °C
Derating: 7A @ 40 °C
Max output power: 292W
Protection: Protected against reversed polarity, short circuit and thermal run-off
Insulation class: Class II
Insulation voltage Primary: 4000VAC
Insulation voltage Secondary: 5700VDC
Electrical safety: EN60601(Edition 3.1)
EMC standards: EN60601-1-2:2015 (Edition 4)
Input terminal: 2-pin IEC 60320 connector
Output terminal: Battery clips
IP rating: IP44
Dimensions: (LxWxH) 210 x 113 x 53mm
Weight: 1150g
Plug Typle: EU Plug
Color: Black

Charge Control (see charger diagram):
Step 0 < 10min (Yellow): Low current start-up for: CC 0.8A±0.2A
when batt volt < 21V
Step 0 > 10min (Red: 4 blinks): Battery voltage too low: 0A / 0V
Step 1 (Yellow): Charge current: 10A ±0.3A
Step 2 (Flash yellow): Charge voltage: 29.2V ± 0.2V
Step 3 (Green): Charge term when current is: < 0.8A
or max. 1 hr.
Restart: 26.4V

APPROVALS:
• DOE compliant
• ISO9001:2015 – Quality management systems
• CE compliant
• Medically certified: EN60601-1 3.1 & EN60601-1-2 4
• UL approved
