Fox's groundbreaking all-in-one three-phase storage system is an advanced battery storage system available in AC-coupled and hybrid variants. It is contained in a compact and stylish floor-mounted unit.
Fox's all-in-one storage solution not only looks sleek in design, but also delivers power and performance. The unit includes a high voltage charge controller that can charge and discharge up to 6 kW continuously. The storage capacity is flexible and expandable, up to 10.4 kWh.
HIGH EFFICIENCY: Charging/discharging efficiency up to 97%.
EASY INSTALLATION: Plug-and-play installation with built-in fuses.
EPS FUNCTION: EPS function for off-grid and emergency power.
UPGRADABLE: Expand storage capacity. Up to 4 batteries can be placed in series.
REMOTE MONITORING: Monitor the system remotely using a web portal or smartphone app.
SECURITY & SECURITY: Enhanced security features using advanced hardware and software protection.
HIGH VOLTAGE: Compatible with the latest high voltage lithium-ion batteries from Fox.
NATURAL COOLING: Natural cooling, wide temperature tolerance and no noisy internal fans.
IP65 NORMAL: Designed to last with maximum flexibility. Suitable for outdoor installation.
The Fox All-In-One is a stylish three-phase stand-alone unit specifications:
Uses FE-HV2600 high voltage batteries
Easy to install
IP65 rating - suitable for outdoor installations
Remote monitoring via web portal or smartphone
Easy battery capacity expansion
Double MPPT - ensures optimal solar production
High efficiency of 97%
CT clamps and gauge included
Note: 4 pcs HV2600 2.6 kWh batteries required for each system.
Weight: 80 kg
Rated power: 8,000 W
Min PPT voltage: 160 V
Max PPT voltage: 950 V
DC Startup voltage: 180 V
DC Shutdown voltage: 160 V
Max input voltage: 1,000 V
Max DC Power: 10,000W
Max AC Power (5 Minutes): 8,800 W
Surge AC Power (1 Second): 16,000 W
Max DC Current: 39.5A
Max DC Inputs: 3
Has DC Fuses: 0
Included Connectors: 6
Euro Efficiency: 97 %
MPPT Quantity : 2
Integrated DC switch?: Yes
Warranty: 5 years
